RG11+Messenger Cable

R11+M, also called RG11 with messenger, stands for RG11 plus a messenger wire. The messenger wire is an additional wire attached to a coax cable, which is to add rigidity to the cable instead of carrying signals. This RG11 with messenger cable is specially used for satellite device and aerial cable installation because its extra steel messenger wire can give greater support to the RG11 cable and reduce sag. In addition, RG11 with messenger is perfect for very long runs or outdoor installation to ensure a stable signal transmission.

Availability:


Inquire

Product Description

Overview

Model NO.: RG11+Messenger

Application: Local Communication Cable, Coaxial Cable, LAN Cable

Conductor Material: BC/CCS/CCA/TC/CU/CCAG

Cover Material: PE/PVC

Type: Coaxial Cable

Material Shape: Round Wire

Conductor Type: Solid

Wire Core Material: Bare Copper Wire

Certification: CE, ISO, RoHS, CPR

Model: Rg11

Brand: Kexun or Newking

Inner Conductor: CCS, Cu ,CCA,Tc,etc.

Insulation: PE,Foaming PE

Shield: Al Foil,Copper Foil

Braiding Material: Al, CCA,Cu, Tcu etc.

Braiding Coverage: 30%, 45%, 60%, 80%, 90% etc.

Jacket: PVC, PE

Color: White, Black, Yellow,Green etc.

Trademark: OEM

Transport Package: Roll,Wooden Spool,Plastic Reel,Gift Box,Pully Box

Specification: Copper or Copper Clad Steel

Origin: Foshan, China

HS Code: 85442000

Construction

(1)Center Conductor: 1.63±0.01mm BC

(2)Dielectric: 7.11±0.10mm FPE

(3)Braid: Al Foil + 112*0.12mm Al/Mg

(4)Jacket: 10.0±0.20mm PVC

(5)Steel: 1.30mm

Options

Inner Conductor:	BC/CCS/CCA/TC/SC Available
Dielectric:	Foam PE/Solid PE
First Shield:	Foil:Copper/ Aluminum Foil,(Un-bonded,Bonded,Double bonded, double un-bonded, Copper colored )
Second Shield:	Al,CCA,BC,TC CCS Available Wire Diameter:0.11,0.12,0.15,0.16mm Available Braiding Net:32#,48#,64#,80#,96#,112#,128#,144#
Jacket:	PVC/PE (black,white,color)
